Loc-Line 50813 Coolant Hose Assembly Kit - 1/2" ID, 7-Piece Acetal Copolymer Coolant System for CNC Machines & Industrial Equipment

Product Description

The Loc-Line coolant hose assembly kit is made of acetal copolymer plastic and includes 7 components to build an assembly: 2 Loc-Line hose segments, 3 round nozzles for outlet flow, and 2 NPT connectors to attach Loc-Line hose to NPT threaded male pipe. The acetal copolymer plastic resists corrosion and moisture and can be used with acetone, alcohol, ethyl, greases, oils, commercial dish detergents, gasoline, lacquer solvents, and sodium hydroxide. The components have a maximum operating temperature of 170 degrees F. The material meets National Sanitation Foundation (NSF)/American National Standards Institute (ANSI) 14, 51, and 61 specifications for use with drinking (potable) water, and complies with Registration, Evaluation, Authorization of Chemicals (REACH) and Restriction of the Use of Certain Hazardous Substances (RoHS) standards. The components connect to other Loc-Line components by a ball-and-socket design that snaps together for a tight seal.SpecificationsMaximum Pressure, 1/4" Inner Diameter30 psi (up to 110 psi with element clamp)Maximum Flow, 1/4" Inner Diameter250 gallons/hourMaximum Pressure, 1/2" Inner Diameter20 psi (up to 110 psi with element clamp)Maximum Flow, 1/2" Inner Diameter478 gallons/hourMaximum Pressure, 3/4" Inner Diameter10 psiMaximum Flow, 3/4" Inner Diameter1,140 gallons/hourLockwood Products manufactures the Loc-Line modular hose system of low-pressure hose and couplings used for coolant, air delivery, smoke and dust removal, and other applications. The company, founded in 1981, is headquartered in Lake Oswego, OR.What's in the Box?Loc-Line acetal copolymer hose segments (2)Loc-Line acetal copolymer round nozzles (3)Loc-Line acetal copolymer connectors, NPT (2)
